I apologize,

But I was curious about the post where there are three red laser beams
and that video with that pointer with 7 blue diodes ... in this regard I wonder,
How do you create such a laser pointer? well 3 or 7 module diodes connected as? and above all how to make them work together with the act of ignition?


BobMc

Well-known member
Joined
Apr 23, 2016
Messages
3,798
Likes
881
Points
113
Sanwu sells a tri-beam laser it uses one diode that has three emitters. Think it was Alaskan ( forgive me if I'm wrong ) that bought just the diode off them and built his own. It was real sweet. Posted some real nice beam shot from it.:drool: Sorry but don't know the video your talking about. Hope you find the info your looking for. :thinking:

Last edited:

Alaskan

Well-known member
Joined
Jan 29, 2014
Messages
10,570
Likes
1,606
Points
113
I was only thinking of buying a tri-beam red, I have a host I think it would go nicely in, but haven't bought one yet.​


Lifetime17

Well-known member
LPF Site Supporter
Joined
Dec 15, 2014
Messages
4,496
Likes
1,218
Points
113
Hi,
Im curious about this tri beam What is the driver set to with this diode ?? It would go nice with a full copper host.. Hmmmm..
Rich:)


Alaskan

Well-known member
Joined
Jan 29, 2014
Messages
10,570
Likes
1,606
Points
113
The G85 tri-beam is the one you want for CW out, the G84 is pulse. The G85 puts out full power at about, or just under 2.2 volts @ 3 amps. Probably a BlackBuck driver should work well that is rated up to 3 amps current.

G85 spec sheet:

https://photos.imageevent.com/qdf_f...edatasheets/laserdiodedatasheets/ML562G85.pdf

Ebay:

1. BlackBuck driver rated at 500-3000 mA: https://www.ebay.com/itm/BlackBuck-...ver-for-M140-NDB7675-NDB7875-etc/152701561115

2. BlackBuck driver rated at 1000-6000 mA: https://www.ebay.com/itm/BlackBuck-6-6A-buck-laser-diode-driver-for-NUBM44-NDB7875-etc/162671640234 - I'd buy this driver instead, you will have some headroom and can use it for other higher power diodes later, if you want:

Last edited:

Encap

Well-known member
Joined
May 14, 2011
Messages
4,577
Likes
1,395
Points
113
Last edited:

Lifetime17

Well-known member
LPF Site Supporter
Joined
Dec 15, 2014
Messages
4,496
Likes
1,218
Points
113
Hi,
Thanks guys now interested in something different i will look into it.

Rich:)
