Tiny RGB's

[RedCowboy]

RGB Laser Modules | Sumitomo Electric

sumitomoelectric.com

A compact RGB LD module - a light source for AR displays (July 2021) - EXALOS AG - High-Performance Light Sources. Made in Switzerland

EXALOS presents a miniaturized, full-color RGB light source module for near-to-eye display systems, incorporating three semiconductor laser diodes (LDs) that are integrated on a free-space, micro-optical bench together with collimation optics and wavelength filters. The ultra-compact package...

www.exalos.com

New Miniature Laser-Based Device to Project Color HD Video on the Retina

At the University of Fukui in Japan, researchers have realized considerable advances in creating a highly compact RGB laser projector with the ability to make a high-definition (HD) projection image.

www.azooptics.com

RGB Laser Diode Micro-module

RGB Micro-modules with normal or superluminescent laser diodes have been announced by EXALOS GmbH, enabling the development of augmented and mixed rea

www.photonics.com

https://www.tdk.com/en/featured_stories/entry_022.html



[Gryphon]

I must have one of these in my life, can you imagine a RBG pen laser!? One of those articles with pictures of physical modules is over 2 years old, have these made it into commercial products yet? My google kung fu is weak and so far I'm not seeing anything.



[RedCowboy]

Not that I'm aware of, but that doesn't mean that they aren't in consumer products, could be in pico projectors or one of the projectors that attaches to modern cell phones, also there is a link to contact them ( Sumitomo ) and they did mention " affordable " so I was thinking maybe a group buy if we can get samples or a small order.

Here's one that advertises laser based, but I don't know what's inside other than it is laser based.

Here's another that's laser, I'm not suggesting that we buy any of these, just finding some that aren't LED.



[Gryphon]

I'm willing to toss some money in the pot



[RedCowboy]

Yes I also want some and the Sumitomo square units say they are 150mw with the collimate lens and the typical 9mm looking units are 45mw with collimate lens, now who's the best member to contact Sumitomo ?



[Shmackitup]

Those little projectors aren't very expensive considering...



[Gryphon]

You saw a price?

EDIT: Missed a post, my bad. Laser based pico projectors have been ripped apart before by members, the laser optical train although small, still usually lends itself best for a pointer with similar dimensions to the projector it came out of. Nothing quite like the form factor of these sumitomo arrays.



[Eidetical]

Here's an even smaller packaging of RGB lasers. I saw them at Photonics West 11 months ago, and believe evaluation kits are around $1500.



[RedCowboy]

It says the TO can package is a 5.6mm..... wow.

https://sumitomoelectric.com/sites/default/files/2020-12/download_documents/82-23.pdf



[Shmackitup]

This one basically is a laser pointer already:



[Lifetime17]

RGB Laser Modules | Sumitomo Electric

sumitomoelectric.com

A compact RGB LD module - a light source for AR displays (July 2021) - EXALOS AG - High-Performance Light Sources. Made in Switzerland

EXALOS presents a miniaturized, full-color RGB light source module for near-to-eye display systems, incorporating three semiconductor laser diodes (LDs) that are integrated on a free-space, micro-optical bench together with collimation optics and wavelength filters. The ultra-compact package...

www.exalos.com

New Miniature Laser-Based Device to Project Color HD Video on the Retina

At the University of Fukui in Japan, researchers have realized considerable advances in creating a highly compact RGB laser projector with the ability to make a high-definition (HD) projection image.

www.azooptics.com

RGB Laser Diode Micro-module

RGB Micro-modules with normal or superluminescent laser diodes have been announced by EXALOS GmbH, enabling the development of augmented and mixed rea

www.photonics.com

https://www.tdk.com/en/featured_stories/entry_022.html

Nowthats a cool module very small for a hand held
Rich



[RedCowboy]

Yes, we can make our own RGB HH and have every color.
Some of the tiny modules are designed for eyeglasses displays, they have a planar waveguide and are lower power, but the Sumitomo with 185mw output as well as the ST-Osram ans Exalos have " Individual collimation lenses & free-space beam combiner, collinear alignment " so I think that is the type we want, we need to test some and see how well aligned they are.

A compact RGB LD module - a light source for AR displays (July 2021) - EXALOS AG - High-Performance Light Sources. Made in Switzerland

EXALOS presents a miniaturized, full-color RGB light source module for near-to-eye display systems, incorporating three semiconductor laser diodes (LDs) that are integrated on a free-space, micro-optical bench together with collimation optics and wavelength filters. The ultra-compact package...

www.exalos.com



[Gryphon]

Very neat little laser based projector in this phone. Fast forward to the 5min mark to see it being opened up

EDIT: I also found this one, fastfoward to 7:20 and it appears to use the same laser projector module

Heres a different version that would be perfect for a 12mm pen laser

https://sid.onlinelibrary.wiley.com/doi/epdf/10.1002/jsid.1078



[atomd]

I'm curious if you can put 3 gain chips in series and just pass-through the previous beam. If there are any absorption losses for different wavelengths in semiconductors. I guess only R->G->B would work
