Fiber corrected 638nm laser diode find on eBAy

kecked

Active member
Joined
Jun 18, 2012
Messages
578
Points
43

looks interesting. Divergence is 1:9. 1:9. Square. With no correction. It sure if this was posted before. Same group repackaging blue diodes in windowed cases with inert gas. I’m impressed.




Alaskan

Well-known member
LPF Site Supporter
Joined
Jan 29, 2014
Messages
12,967
Points
113
Check with CDBEAM777, he has some of these and I believe, characterized them.


kecked

Active member
Joined
Jun 18, 2012
Messages
578
Points
43
Yea I’m sending email to see if they will glue two to a pbs cube and the do a second with a blue and green. One dichro only then.


Alaskan

Well-known member
LPF Site Supporter
Joined
Jan 29, 2014
Messages
12,967
Points
113
Problem I have been having with all laser diodes is the angles of their outputs are not consistent enough :( I wonder if their adding a FAC by hand might skew it even more.


Shmackitup

Active member
LPF Site Supporter
Joined
Aug 31, 2016
Messages
193
Points
43
I have some of these as well. The FAC doesn't really do too much once you add a collimator lens. It goes back to being a rectangle when focused.


Alaskan

Well-known member
LPF Site Supporter
Joined
Jan 29, 2014
Messages
12,967
Points
113
Damn, I was so hopeful, but thank you for the info.


Unown (WILD)

Well-known member
Joined
Sep 4, 2020
Messages
398
Points
63
I bought this and totally forgot I had it. I should complete the build and see how well it does with a g2 and g8 lens.



aaronnoraa

Active member
Joined
Jun 20, 2015
Messages
182
Points
43
There was something that I remembered about these diodes, that for the FAC to be able to do it's job you must use a long FL lens (like, really long, enough that it will need to be larger than what will fit on a 12mm module) to allow the beam to expand enough that the profile is square when it inputs the lens, then the beam will stay square after collimation.
