1W 532nm from auction.

paul1598419

Well-known member
Joined
Sep 20, 2013
Messages
14,216
Likes
2,213
Points
113
Aw, shucks.


Nexgen

Active member
Joined
Nov 11, 2016
Messages
309
Likes
192
Points
43


This driver has 6 pots, thick wire is LD. But I don’t know how to power up the board. I’ll be back from vacation on Saturday and try to power this thing up. :san:

Edit: I see mid pot has no glue on it. Might be dead LD , who knows.

Laser head has all warranty stickers on it. So I guess that fine

Last edited:

Nexgen

Active member
Joined
Nov 11, 2016
Messages
309
Likes
192
Points
43
My post is making me laugh. Something went wrong with my brain definitely .

I want to see opinions about driver, otherwise I’ll try to run LD directly from my PSU

Last edited:

paul1598419

Well-known member
Joined
Sep 20, 2013
Messages
14,216
Likes
2,213
Points
113
Can you post more than just one view of the driver board? Would like to see all sides of it. If fact, I'd like to see everything you have concerning this laser.


Nexgen

Active member
Joined
Nov 11, 2016
Messages
309
Likes
192
Points
43
Here are some pics. Managed to open laser head and found out that glue is like a rock there, it would be hard to get inside of the module.











:thanks:


paul1598419

Well-known member
Joined
Sep 20, 2013
Messages
14,216
Likes
2,213
Points
113
From what I can see, I suspect you need a +5 volt supply around 20 amps to connect to the driver for power. These are available inexpensively on eBay new for around $20.00 or less, IIRC. This is similar to my 1300 mW 532nm laser.


Nexgen

Active member
Joined
Nov 11, 2016
Messages
309
Likes
192
Points
43
I have tested the laser, output is low and threshold is around 2.5A and output remains low till 5A. Most likely it needs a pump replacement, don’t think it’s a misalligned as it’s all rock steady inside.

I tried to unscrew back of the module and no success. Pics:






Last edited:

paul1598419

Well-known member
Joined
Sep 20, 2013
Messages
14,216
Likes
2,213
Points
113
There is always a chance you might find a pump diode cheap on eBay. I would put it all back together and go hunting. A new one will be too high. Maybe you can find just the head for this cheap. That is how I would proceed.


Nexgen

Active member
Joined
Nov 11, 2016
Messages
309
Likes
192
Points
43
There is always a chance you might find a pump diode cheap on eBay. I would put it all back together and go hunting. A new one will be too high. Maybe you can find just the head for this cheap. That is how I would proceed.
How about this one? If I run it 15A it will settle around 10w. It’s a bar and I don’t know how to make 2x2mm spot with this diode.

https://www.ebay.com/itm/Coherent-L...263645436055?_trksid=p2349526.m4383.l4275.c10

Fiber coupled:

https://www.ebay.com/itm/Coherent-F...m=173259849548&_trksid=p2047675.c100009.m1982

Last edited:

diachi

Well-known member
Joined
Feb 22, 2008
Messages
9,568
Likes
1,386
Points
113
How about this one? If I run it 15A it will settle around 10w. It’s a bar and I don’t know how to make 2x2mm spot with this diode.

https://www.ebay.com/itm/Coherent-L...263645436055?_trksid=p2349526.m4383.l4275.c10

Fiber coupled:

https://www.ebay.com/itm/Coherent-F...m=173259849548&_trksid=p2047675.c100009.m1982

Fiber coupled is the best option, makes getting the spot down to a reasonable size fairly easy. Those bar diodes use 19 multimode emitters so the output is a mess without either a lot of optics or fiber coupling.

The fiber coupled modules use the same diode array with a fiber bundle, one fiber coupled to each emitter on the array.


paul1598419

Well-known member
Joined
Sep 20, 2013
Messages
14,216
Likes
2,213
Points
113
That's good advice, Nexgen. You will have a nightmare trying to get those diodes focused into your crystals without some kind of optical array.


Nexgen

Active member
Joined
Nov 11, 2016
Messages
309
Likes
192
Points
43
Last edited:

diachi

Well-known member
Joined
Feb 22, 2008
Messages
9,568
Likes
1,386
Points
113

Nexgen

Active member
Joined
Nov 11, 2016
Messages
309
Likes
192
Points
43
Best option so far is the same 10w Diode that was used before it died. New will cost $248, plus I don’t have test load to test driver current, etc. This laser was outputting way more than 1 or 2w. I don’t know. Risk is big according to my budget. This is good example and you will learn something new always when the problem is solved. As Paul mentioned - there’s a unit on eBay that costs $409 and outputs 1.3W. Best I can get is to put all this aside till best times. I’m currently enjoying my new 473nm 300mw unit, enough fun for me :rolleyes:
