Need help finding IR laser Diode with the following specs

melonkiller

New member
Joined
Nov 28, 2010
Messages
5
Points
0
Hey guys I'm new here and I'm a really big noob on lasers. I'm looking for an IR laser Diode with the following specs

Class: IIIb
Output Power: 600 microwatts
Wavelength: 830nm +/- 20nm

I've been looking around but I haven't been able to find a IR laser diode with the output power of 600 microwatts.

This is for a project I'm undertaking for replacing the visible laser diode of a laser weapon sight (Insight M6X) to an IR laser.

(Also if anyone has undertaken this feat please let me know how you did it LOL)

Thanks guys!


melonkiller

New member
Joined
Nov 28, 2010
Messages
5
Points
0
Sorry about that I was going by what it said in the manual. Thanks for the clarification.



I guess 500 MW would be enough. Thanks

Last edited:

melonkiller

New member
Joined
Nov 28, 2010
Messages
5
Points
0


I'm trying to switch the laser on this so I can use it in conjunction with Night vision.


JLSE

1
Joined
Dec 13, 2007
Messages
3,587
Points
0
I have 500mW 836nm NIR diodes.. They are c-mount though.
Dont know if you will find the range your looking for in 5.6mm or 9mm LD's.


DrSid

New member
Joined
Jul 17, 2010
Messages
1,516
Points
0
He says 600 MICRO Watts .. not MILLI Watts.


RA_pierce

Well-known member
Joined
Sep 16, 2007
Messages
3,411
Points
83
What type of night vision?
And what wavelength is the laser that is currently installed? I'm guessing 635-660nm?

600 microWatts (µW) is equal to 0.6 milliWatts (mW), so 600µW is Class I.

Regardless, you may be able to use any diode >780nm. The output power you need is determined by the kind of illumination you require.
780nm and 808nm diodes are the most common and cheapest near IR diodes available and in a wide range of power outputs.

Last edited:

melonkiller

New member
Joined
Nov 28, 2010
Messages
5
Points
0
Current wavelength is 640nm +/-40

I'll be using the IR laser with ITT Gen III PVS-14s


Cyparagon

Well-known member
Joined
Sep 12, 2007
Messages
9,586
Points
113
something like this 3mW module for $4 will work great for you. Night vision isn't wavelength dependent and can often see anything down to 990nm or more. If you're feeling particularly adventurous, you can use the diode from any old CD drive.

600µW is Class I.
Class 2, you mean. Class 1 has to be <390µW according to wikipedia.


LazyBeam

New member
Joined
Jun 12, 2010
Messages
446
Points
0
There are individuals who offer this service for a fee already.
But be prepared to pay $75+ for the service or more for entire rebuilt unit.
